IFM 01D102 Photoelectric Distance Sensor

IFM 01D102 O1D102 O1DLF3KG Photoelectric Distance Sensor Class 2 M12 18-30V DC,
IFM 01D102 O1D102 O1DLF3KG/IO-LINK Distance Sensor

Specification/Additional Details

• Sensor Type : Photoelectric
• Brand : IFM
• Model : 01D102/O1D102
• Laser protection class : 2
• Operating voltage : 18 ~ 30V DC
• Current consumption : < 150mA

• Reverse polarity protection : Yes

• Number of inputs and outputs : Number of digital outputs: 2; Number of analogue outputs: 1

• Electrical design : PNP

• Output function : NO/NC (programmable)

• Measuring range : 0.2 ~ 3.5m (black glossy surfaces)

• Communication interface : IO-Link

• Transmission type : COM2 (38,4 kBaud)

• Ambient temperature : -10 ~ 60 DegreeC

• Connection : Connector: 1 x M12
