SMC Solenoid Valve 10-VQ110U-5M0-X46 Vacuum Ejector

SMC 10-VQ110U-5MO-X46 3-port valve, Panasonic SMT Valve KXF0DX8NA00 N510054843AA 10-VQ110U-5M0-X46

The 10-VQ110U-5M0-X46 is a 3-port, single solenoid valve manufactured by SMC Corporation. It is part of the VQ series and is often used in automated machinery, including Panasonic and other SMT equipment.

Key specifications

• Valve type: 3-port, single solenoid valve.
• Fluid: Air/inert gas.
• Operation: Suitable for applications requiring high speed, frequent operation, and a stable response time.
• Mounting: Features an innovative mounting method that allows valves to be changed without completely disassembling the manifold.
• Fittings: Built-in one-touch fittings.
• Operating pressure range: 0.1 MPa to 0.7 MPa.
• Rated voltage: 24 VDC.
• Ambient and fluid temperature: -10 to 50°C.
