Sanyo Denki 103H7822-0440 Stepping Motor

Sanyo Denki StepSyn 103H7822-0440 Stepping Motor 2 Phase Hybrid Rare Earth Magnet Technology, Single Shaft, 19.1mm Shaft Length, Unipolar, 1.8° Step Angle, 1.17 N-m Max Torque, 2A Current Rating

Specification/Additional Details

• Number of Phase : 2 Phase
• Step Angle : 1.8 Degree
• Voltage : 24V DC
• Brand : Sanyo Denki
• Model Number : 103H7822-0440
• Coil Type : Unipolar

• Torque : 1.17N-m max.

• Current Rating : 2A

• Voltage Rating : 24V DC max.

• Shaft Length : 19.1mm

• Flange Size : 60mm

• Shaft Diameter : 8mm

• Connection Type : Connector
