Schneider Electric 16CH 140 ACI 040 00 Analog Input Module 3A-14

Schneider Electric 16CH 140 ACI 040 00 Analog Input 16-Channel Module 3A-14,
Analog Input Module 140 ACI 040 00 Modicon Quantum 16 -Schneider Electric 140ACI04000

Specification/Additional Details

• Number of Channels : 16
• Brand : Schneider Electric
• Usage/Application : Industrial
• Model Name/Number : 140ACI04000
• Range of product : Modicon Quantum automation platform
• Product type : Analogue input module
• Type of filter : Single pole low pass - 3 dB at 34 Hz +/- 25 %

• Analogue input number : 16

• Input type : Differential

• Addressing requirement : 17 input words

• Absolute maximum input : 30 mA

• Input impedance : 250 Ohm

• Common mode rejection : > - 90 dB 60 Hz

• Isolation between channels and bus : 1780 V AC for 60 s

• Bus current requirement : 360 mA

• Power dissipation : 5 W

• Module format : Standard
