Schneider Electric 140DDO35300 Discrete Output Module

Schneider Electric TSX Quantum 140 DDO 353 00 24VDC 4X8 Source 140DDO35300 Discrete Output Module,
32CH 24VDC 140 DDO 353 00 Output Module Schneider

Specification/Additional Details

• Number of Channels : 32
• Model Name/Number : 140DDO35300
• Brand : Schneider Electric
• Product Type : DC discrete output module
• Discrete output number : 32
• Discrete output logic : Positive logic (source)
• Discrete output voltage : 24V DC

• Output voltage limits : 19.2 to 30 V

• Absolute maximum output : 56 V 1.3 s decaying pulse

• Maximum voltage drop : <0.4 V 0.5 A

• Maximum load current : 16 A per module 4 A per group

• Surge current : 5 A 0.0005 s

• Maximum leakage current : 0.4 mA 30 V

• Isolation between channels and bus : 1780 Vrms DC for 1 minute

• Isolation between group : 500 Vrms DC for 1 minute

• Protection Type : Internal output protection by 5 A fuse per group

• Power dissipation : 1.75 W + (0.4 V x total module load current)

• Bus current requirement : 330 mA

• Module format : Standard
