183388 DEK Loader Sensor CH-8501

CH-8501 DEK Loader Sensor FHDK 14P5101/S35A Part Number 183388, DEK SMT Spare Parts,
Baumer Diffuse Photoelectric Sensor with Background Suppression FHDK 14P5101/S35A 20 mm to 350 mm Sensing Distance, PNP Light/dark operate, 10 to 30 VDC Supply Voltage, < 100 mA Output Current, M8 4-pin connector, Mechanical 10-turn adjustment for sensing distance, Short-circuit and reverse polarity protection.
Applications: Ideal for applications requiring reliable object detection with background suppression.

Specification/Additional Details

• Sensor Type : Diffuse sensor with background suppression
• Short circuit protection : Yes
• reverse polarity protection : Yes
• Connection : M8 4-pin connector
• Model : FHDK 14P5101/S35A
• DEK Part Number : 183388

• Sensing Distance : 20 mm to 350 mm

• Output Type : PNP

• Output Function : Light/dark operate

• Supply Voltage : 10 to 30 VDC

• Usage : DEK SMT Screen Printer Machine

• Application : Ideal for applications requiring reliable object detection with background suppression
