2046A MITUTOYO Plunger Dial

2046A MITUTOYO Plunger Dial
Specifications

• Range: 0-10 mm
• Graduation (Resolution): 0.01 mm
• Accuracy: ±0.013 mm (overall accuracy)
• Dial Reading: 0-100
• Measuring Force: 1.4 N or less
• Stem Diameter: 8 mm
• Back Type: Lug back (for mounting purposes)
• Contact Point: Carbide tipped, with M 2.5 x 0.45 thread
• Features: No through screw holes on the frame and O-rings for increased dust and water resistance, hardened stainless steel stem and spindle for durability, and a glare-free, scratch-resistant crystal coating.
