22A-B4P5N104 Allen-Bradley PowerFlex 4
Core Technical Specifications
The component architecture relies on standard low-power 3-phase inversion to drive 230V industrial motors safely.
| Specification Parameter | Technical Rating & Value |
|---|---|
| Series / Family | PowerFlex 4 (Bulletin 22A) |
| Motor Power Rating | 0.75 kW (1.0 Horsepower) |
| Output Current | 4.5 Amps continuous |
| Input Voltage Range | 200–240V AC, 3-phase (180–265V operational) |
| Enclosure Protection | IP20, NEMA Type Open |
| Operational Interface | Fixed, integrated digital keypad with LED display |
| Communication Bus | Integral RS-485 serial communication port |
Key Operational Features
- Control Algorithm: Employs sensorless vector control to deliver high torque and stable regulation at low motor speeds. [1, 2]
- Dynamic Braking: Features an internal, built-in dynamic braking transistor to handle regenerative energy from decelerating loads.
- I/O Control Modes: Supports both sink and source modes via a configurable digital input DIP switch, and accepts unipolar analog control signals.
- Overload Threshold: Provides robust hardware protection, handling a 150% overload for up to 60 seconds or a 200% overcurrent fault spike.
