2MGKHA071000,24VDC CAMERA FOR FUJI MACHINE
Component Overview & Applications

• Machine Head Compatibility: It is specifically designed as the component vision / IPS camera mounted on Fuji NXT V12 placement heads.
• Power Specification: Operates on standard industrial 24VDC automation power lines.
• Primary Function: Provides optical scanning, component orientation verification, and alignment tracking during pick-and-place high-speed assembly.

Associated Assembly PartsWhen maintaining or rebuilding the camera layout on a Fuji NXT V12 head, it often shares the sub-assembly setup with these parts:

• OFC Flexible Cable: Part XK05930 / XK05933 (The Optical Fiber Cable or flex harness used to route the vision sensor data to the system controller).
• IPS Lamp Board: Part 2EGKHA003800 (Provides direct lighting for the vision system).
• Adjusting Bracket: Part 2MGKHA011000.
