2W025-08 electric control valve

2W025-08 SOLENOID VALVE
Technical SpecificationsThe standard alphanumeric code breaks down its exact mechanical specifications:

• Model Series (2W): Indicates a 2-position, 2-way direct drive mechanism.
• Orifice Size (025): Represents an internal flow opening diameter of 2.5 mm.
• Port Size (08): Denotes a standard 1/4" inch thread connection (available in NPT or BSPP depending on the manufacturer).
• Operation Mode: Normally Closed (N/C), meaning the valve remains shut until an electric current energizes the coil to open it.
• Working Pressure: Operates from 0 to 10 bar (0 ~ 1.0 Mpa), enabling pressure-free start functionality.
• Body Material: Typically forged from solid brass with an internal NBR or Viton rubber seal.
