31K15RGN-C AC speed control induction gear motor

31K15RGN-C AC speed control induction gear motor
Key Specifications

• Power Output: 15 Watts
• Voltage: 220V - 240V AC (Single Phase)
• Frequency & Base Speed:
  • 50 Hz: 90 to 1350 RPM (Rated motor speed without gearbox is roughly 1440 RPM)
  • 60 Hz: 90 to 1650 RPM
• Motor Type: Induction Speed Control Motor (K Series / World K Series)
• Frame Size / Dimension: 70 mm square flange

Companion Components

• Gearhead Pairing: This motor is commonly mated with a 3GN series gearhead (such as the 3GN-15K or 3GN-5-K) to multiply torque and bring the output rotation down to specific conveyor speeds.
• Speed Controller: The "R" in the part number denotes that it features a built-in tachometer generator loop, allowing it to be connected directly to an external AC speed controller to adjust operational RPM.
