35A-ACA-DEAA-1BA SOLENOID VALVE

35A-ACA-DEAA-1BA SOLENOID VALVE
Technical Specifications

• Operating Voltage: 12V DC
• Power Consumption: 6 Watts
• Flow Capacity: 0.15 Cv
• Pneumatic Port Size: 1/8" BSPPL threaded female
• Pressure Range: Full vacuum up to 120 PSI
• Electrical Connection: 18-inch (45 cm) flying leads
• Manual Override: Non-locking recessed manual operator
• Installation Style: Individual inline configuration

Key Operational Strengths

• Balanced Poppet Design: This unique engineering design permits exceptional multi-use versatility. It can be safely plumbed as a 2-way or 3-way valve, and configured as either Normally Open (NO) or Normally Closed (NC).
• High Frequency & Consistency: Built with a short stroke design and an incredibly strong return spring. This delivers fast shifting speeds, consistent cycle repetitions, and prevents sticking under extreme shifts.
• Universal Media Compatibility: Can be operated reliably with compressed air, vacuum systems, or inert gases. It performs exceptionally well on both lubricated and non-lubricated air supply streams.
