3C-D-A93L magnetic reed auto-switch sensor

Name: 3C-D-A93L magnetic reed auto-switch sensor
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

3C-D-A93L magnetic reed auto-switch sensor

Technical Specifications

Switch Type: Reed Switch (SPST-NO / Normally Open)
Operating Voltage: 24 VDC / 100 VAC
Load Current Range: 5 to 40 mA
Indicator Light: Red LED illuminates when the switch is turned ON
The "L" Suffix: Denotes a longer factory lead wire option (typically a 3-meter cable) for flexible wiring.
Internal Voltage Drop: 2.4 V or less

Key Applications & Performance

Cylinder Integration: Slides directly into the integrated mounting grooves or brackets of SMC pneumatic cylinders.
PLC Compatibility: Designed to interface seamlessly with PLC controllers, relays, and industrial automation networks.
Environmental Resistance: Built with a durable composite enclosure capable of handling operating temperatures from -10°C to 60°C
