3GN 15K GEAR ZD

3GN 15K GEAR ZD
The 3GN 15K is a parallel shaft gearhead, commonly paired with 15W AC induction or DC gear motors, typically with a 70mm or 90mm frame size.

• Gear Ratio: 15:1.
• Shaft Type: Parallel Shaft, GN-K type.
• Output Shaft Diameter: 10 mm (metric shaft).
• Compatible Motor Power: Often used with 15W motors.
• Permissible Torque: Up to 1.3 N·m (at 60 Hz) or 1.5 N·m (at 50 Hz) when paired with a compatible 15W motor.
• Frame Size: Typically used with a 2.76 inch (70 mm) frame size motor
