3IK15RGN-C + 3GN15K ZD Link Conveyor Motor + Gear
Key Specifications

• Motor Model: 3IK15RGN-C (15W AC Speed Control / Induction Motor, K Series)
• Gearhead Model: 3GN15K (Parallel shaft gear reducer with a 15:1 gear ratio, 70mm frame size)
• Voltage & Phase: 220V AC, Single Phase
• Power Output: 15 Watts
• Speed Control / Range: Typically 90–1400 rpm (at 50 Hz) depending on the controller usage
• Frame / Flange Size: 70 mm × 70 mm square flange
• Capacitor: 1.5 µF / 450 VAC (typically included with the motor)
• Weight: Approximately 1.2 kg (Motor) + 0.5 kg (Gearhead)

Important Notes

• Oriental Motor Discontinuation: The Oriental Motor equivalent/version of 3IK15RGN-C lists a discontinuation timeline (order deadlines around early 2027), though ZD Motor and compatible equivalents remain widely available through industrial suppliers.
• Testing Precaution: Do not test insulation resistance or dielectric strength while a speed controller is hooked up to the motor. [
