4V310-08 24VDC SOLENOID VALVE

4V310-08 24VDC SOLENOID VALVE
Key Specifications

• Type: 5/2 Way Single Solenoid (5 port, 2 position)
• Port Size: 1/4" PT/BSP (Inlet, Outlet, and Exhaust)
• Working Voltage: 24V DC
• Operating Pressure Range: 0.15 to 0.8 MPa (21 to 114 psi)
• Body Material: Aluminum alloy
• Lubrication: Not required (optional ISO VG32 if used)
• Max Acting Frequency: 4 cycles/second
• Working Temperature: -20°C to 70°C
