SURPA 518-2 Online ESD Wrist Strap Monitor

ESD Wrist Strap Online Monitor 518-2 Dual Constant Anti Static Wristband Tester Alarm

The 518-2 ESD Wrist Strap Monitor is a compact, real-time monitoring device for electrostatic discharge (ESD) protective wrist straps, primarily used in electronics manufacturing and repair facilities. It features dual channels, allowing two operators to be monitored simultaneously.

Features and Operation

The device is designed for continuous, reliable monitoring and alerts the user to any disconnections or static build-up issues through both visual (LED) and audible (buzzing sound) alarms.

• Continuous Monitoring: Provides uninterrupted monitoring of the wrist strap and ground connections to ensure consistent ESD protection.
• Dual Channels: The specific SURPA 518-2 model features two independent channels, allowing the monitoring of two wrist straps simultaneously.
• Real-time Alerts: When the system is working normally, a green light is illuminated. If a malfunction occurs in the static discharge path (e.g., a broken connection), a red light flashes and a buzzing sound is emitted.
• Adjustable Sensitivity: The alarm sensitivity can be adjusted to suit the individual user's body resistance.
• Compatibility: It is designed to be compatible with most standard wrist straps that use a banana plug connection.

Specifications
