6314N / 2TDHPU ebmpapst axial Brushless DC fan 4-Wire

Key Specifications

• Dimensions: 172 mm x 172 mm x 51 mm
• Operating Voltage: 24V DC
• Power & Current: 84W (3.5A nominal draw, with variants or peak operations reaching higher ratings)
• Speed: 7200 RPM
• Airflow: ~500 to 571 CFM (Cubic Feet per Minute)
• Noise Level: ~75 dBA
• Bearing Type: Dual ball bearing for extended longevity
• Connection: 4-wire configuration (supporting PWM speed control and tachometer speed-monitoring output)
• Material: Die-cast aluminum housing with a robust metal frame
