6906ZZ NTN BEARING
6906ZZ NTN BEARING
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Key Specifications & Dimensions
According to technical datasheets from NTN Americas and component distributor the exact physical parameters include:
- Inside Diameter (Bore): 30 mm
- Outside Diameter: 47 mm
- Overall Width: 9 mm
- Basic Dynamic Load Rating: 7.25 kN (7,250 N)
- Basic Static Load Rating: 5.00 kN (5,000 N)
Feature Breakdown
- ZZ Designation: Indicates non-contact metal shields on both sides of the bearing. These retain the factory-packed lifetime grease while providing mechanical protection against dust and larger external particles without adding extra frictional torque.
- 6900 Series Configuration: Represents a "thin-section" geometry. It maintains a relatively large internal bore (30mm) while keeping the outer shell slim (47mm), making it perfect for lightweight, compact applications.
- Cage & Clearance: Built with a robust pressed-steel cage to evenly space the rolling elements and a standard CN (normal) internal radial clearance.
