6ES7132-6BH01-0BA0 POWER MODULE

6ES7132-6BH01-0BA0 POWER MODULE
Core Technical Specifications

• Rated Voltage: 24V DC
• Number of Channels: 16 digital outputs
• Output Current: Max 0.5 A per channel, total max 8 A per module
• Output Type: Source output (PNP, P-switching)
• Power Loss: Typically 1 W
• Protection: Short-circuit and reverse polarity protection

System Compatibility

• Base Unit (BU): Requires BU type A0
• Color Code: CC00
• Software: Configurable using STEP 7 TIA Portal (V14 or higher) or standard STEP 7 (V5.5 SP3 or higher)
• Hardware: Part of the active SIMATIC ET 200SP product family
