6L2-450V YANHAO voltmeter
Key Specifications

• Model: 6L2-V
• Type: Magnetoelectric analog pointer gauge
• Measuring Range: 0–450V AC (direct access or via transformer depending on configuration)
• Accuracy Class: 1.5 or 2.5
• Dimensions: Standard panel cutout size of 80mm x 80mm
• Damping Time: Less than 4 seconds
• Operating Position: Vertical mounting (allowable inclination ±5°)
• Operating Temperature: -20°C to +55°C
