750104 Safety Relay, 24 VDC

750104 Safety Relay, 24 VDC

Product Overview   750104 is a PNOZ s4 series safety relay for monitoring E-STOP pushbuttons, safety gates and light beam devices. This safety relay meets the requirements of EN 60947-5-1, EN 60204-1 and VDE 0113-1 as safety component in accordance with the Lift Directive 95/16/EC and EN 81-1.

• Positive guided relay outputs of 3 safety contacts (N/O), 1 auxiliary contact (N/C) instantaneous
• 1 semiconductor output
• Connector can be used to connect 1 PNOZsigma contact expander module
• Operating modes can be set via rotary switch
• LED indicators
• Plug-in connection terminals either spring loaded terminal or screw terminal
• Supply voltage is 24VDC or 48VAC/VDC to 240VAC/VDC

Technical SpecificationsCoil Voltage

24VDC

Product Range

PNOZ s4 Series

Contact Current

6A

Contact Voltage AC Nom

240V

Contact Material

Silver Copper Nickel

SVHC

No SVHC (21-Jan-2025)

Contact Configuration

3PST-NO

Relay Mounting

DIN Rail

Relay Terminals

Screw

Contact Voltage DC Nom

24V

IP Rating
