821003029 AVENTIC Pilot-operated non-return valve, Series NR02
821003029 AVENTIC Pilot-operated non-return valve, Series NR02
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
AVENTICS™ Pilot-operated non-return valve, Series NR02 0821003029
Specifications
| Type | Poppet valve |
| Mounting | installing in piping |
| Compressed air connection 1 | G 3/4 |
| Compressed air connection type 1 | Internal thread |
| Compressed air connection 2 | G 3/4 |
| Compressed air connection type 2 | Internal thread |
| Compressed air connection 12 | G 1/8 |
| Nominal flow Qn 1 to 2 | 4600 l/min |
| Nominal flow Qn 2 to 1 | 4500 l/min |
| Min. working pressure | 1 bar |
| Max. working pressure | 12 bar |
| Min. ambient temperature | -10 °C |
| Max. ambient temperature | 60 °C |
| Min. medium temperature | -10 °C |
| Max. medium temperature | 60 °C |
| Medium | Compressed air |
| Weight | 0.52 kg |
| Housing material | Aluminum |
| Seal material | Acrylonitrile butadiene rubber |
