Hakko 900M Series Soldering Stations Tip/Bit 900M-T-1.2D chisel/flat Shaped

Hakko Soldering Iron Tip/Bit 900M T 1.2D Chisel-shaped, 900M-T-1.2D HAKKO Bit

The 900M-T-1.2D is a type D soldering tip with a 1.2 mm diameter, widely compatible with Hakko 900M series soldering stations and various other 936-type stations.

Tip specifications

• Tip shape: Type D (chisel/flat)
• Tip diameter (point diameter): 1.2 mm
• Outer diameter: 6.5 mm
• Inner hole diameter: 4 mm
• Material: Metal, with a copper-based structure for better heat conduction. Tips are often made of oxygen-free copper with iron, nickel, and chromium plating for durability and resistance to oxidation.
• Length: 43 mm
• Application: Precise and efficient soldering for a variety of electronic and electrical applications, and suitable for lead-free soldering.

Compatible soldering stations and irons

The 900M-T-1.2D soldering tip is compatible with the following stations and irons:

• Hakko: 936, 937, 928, 933, 907, 900M, 900M-ESD,  and FX-888D
• Bakon: 936, 938, Quick: 936, Other brands: Aoyue, Yihua, Atten, Vastar, Sywon, Tabiger, SOAIY, and X-Tronic 936 soldering stations.
• General: Many other ceramic heating-based soldering irons with the same inner and outer diameters.
