Bevel-shaped Soldering Iron Tip/Bit 900M-T-2C

Hakko 900M-T-2C Replacement Soldering Tip, 900M-T-2C 2mm Width Bevel Soldering Bit Solder Iron Tip

The 900M-T-2C soldering tip is a bevel-shaped tip used for soldering tasks requiring a mix of precision and heat transfer. The "900M" refers to its compatibility with the popular 900M series of soldering irons and stations, including models like the Hakko 936.

Key specifications

• Tip shape: Bevel
• Tip width: 2 mm
• Material: Oxygen-free copper with various plating layers, often iron, nickel, and chromium, to improve heat conduction and corrosion resistance.
• Outer diameter: 6 mm
• Inner diameter: 4 mm

Best for

A 900M-T-2C tip is a versatile choice for soldering a variety of components.

• Precision soldering: The angled bevel is ideal for working with small components on printed circuit boards (PCBs).
• Maximum heat transfer: It is designed to transfer heat efficiently from the iron's heating element to the tip, making it suitable for soldering components with moderate thermal mass.
• Drag soldering: The flat face of the bevel tip makes it useful for drag soldering, a technique often used for soldering integrated circuits (ICs) and other surface-mount components.
