Soldering Iron Tip/Bit 900M-T-B Conical

900M-T-B Replacement Soldering Iron Tip, 900M-T-B Solder Welding Replacement Tip

The 900M-T-B soldering tip is a general-purpose, conical tip for various soldering tasks, compatible with many 900M series soldering stations, including many Hakko models.

Specifications

• Tip shape: Conical or round sharp. It can be used in any direction and is effective for soldering small-to-large surfaces.
• Material: Made with a copper core plated with iron, and often nickel and chrome, for efficient heat transfer and corrosion resistance.
• Temperature range: Operates effectively between approximately 200°C and 480°C.
• Dimensions:
  • Length: ~43mm (1.7 inches).
  • Outer diameter: ~6.5mm.
  • Inner diameter: ~4mm.
• Point diameter: ~1.2mm.

Compatible soldering stations

The 900M-T-B tip is compatible with soldering stations that use 900M series tips. These include:

Hakko models, such as 936, 937, 938, 969, and 907
Aoyue, Atten, Quick, Radio Shack, and Yihua stations that use 900M series tips
X-Tronic models (with the exception of some models like the 3010-XTS)
Some Weller and Tenma soldering stations.
