AC58/0012EK.42CLI Rotary Encoder

AC58/0012EK.42CLI Rotary Encoder
Model Breakdown & Technical Specifications

• Series Designator (AC58): Refers to the industry-standard 58 mm housing diameter made of robust aluminium.
• Resolution (0012): Provides a 12-bit single-turn resolution, yielding exactly 4,096 unique positions per 360-degree revolution.
• Mechanical Interface (EK): Features a solid 10 mm diameter shaft mounted with a clamping flange layout for rigid mechanical coupling.
• Supply Voltage (42): Operates on a standard industrial 10 to 30 V DC power range.
• Communication Interface (CLI): Utilizes a dedicated industrial bus connection protocol, rendering it widely interchangeable with alternative interfaces in the same family
• Protection Class: Rated at IP64 to safeguard internal electronics against fine dust particles and water splashes.
• Procurement and Availability

Because this specific part number is a specialized piece of automation hardware, availability varies depending on your requirements:

• Official Distribution & Global Logistics: You can request official quotes, review alternative variations (like the parallel-wired or SSI models), and check regional availability directly from technical providers like  or industrial supply distributors such as
