ACL800 Digital counter meter
ACL800 Digital counter meter
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Key Technical Specifications
| Feature and | Specification Details | Source |
|---|---|---|
| Measurement Range | \(10^3 \text{ to } 10^{12} \text{ ohms (or ohms/square)}\) | |
| Test Voltages | Dual capability: \(10\text{V}\) and \(100\text{V}\) | |
| Accuracy | \(\pm 10\%\) to \(\pm 25\%\) (depending on the resistance decade range) | |
| Display Type | Alphanumeric Digital LCD (displays exact numerical values instead of LEDs) | |
| Environmental Sensors | Relative Humidity (\(10\% \text{ to } 90\% \text{ RH}\)); Temperature (\(32^\circ\text{F to } 100^\circ\text{F}\)) | |
| Power Source | \(9\text{V}\) Battery or \(110\text{V}\) Power Adapter |
Core Applications and Features
- Complete Compliance Auditing: It directly measures Point-to-Point (RTT) and Resistance-to-Ground (RTG) parameters. The instrument complies with global ESD association standards including
- Material Evaluation: The meter verifies compliance for anti-static mats, industrial floor finishes, conductie paints, wrist straps, smocks, ESD footwear, and static shielding bags.
- Integrated Environmental Logging: Because ambient moisture and temperature directly influence static dissipation, the integrated climate sensors eliminate the need for a separate hygrometer.
- Full Audit Kit: The package includes the baseline tester unit, two calibrated 5-pound disk probes, heavy-duty connection shielding cables, a NIST-traceable calibration certificate, and a foam-lined carrying case.
