Pilot Lamp AD22-22DS LED Indicator Lamp

22mm AC 220V LED Indicator Lamp AD22-22DS, 22mm Led Indicator Signal Lamp

The AD22-22DS is a series of LED indicator lights used as signal and warning lamps in industrial equipment and control panels. AD22-22DS recognizable by their 22mm mounting size and have a long lifespan due to their LED technology.

Key features

• LED technology: These indicator lights use bright LED chips for illumination, providing pure, high-luminosity colors. They are a modern, energy-efficient alternative to older incandescent and neon indicator lamps.
• Long service life: With an expected continuous working life of 30,000 to over 50,000 hours, these lamps require very little maintenance.
• Versatile applications: AD22-22DS lights are used across a wide range of machinery and equipment. Applications include:
  • Industrial control panels
  • Electrical systems
  • Telecommunication systems
  • Mining machinery
  • Textile machinery
• Variety of colors: To indicate different statuses, the lights are available in several colors, including red, green, yellow, blue, and white.
• Standard size: The lamps feature a standard 22mm panel-mount design, making them easy to install into equipment with a corresponding mounting hole.
• Voltage options: The AD22 series offers broad voltage compatibility for both AC and DC systems, with models covering voltage ranges such as 12V, 24V, 110V, 220V, and 380V.
• Durable construction: The lamp's housing is made from durable, high-strength plastic, providing good shock resistance and longevity.
• Mounting and terminals: The design includes a single back-of-panel locknut for secure installation and screw-clamp terminals for straightforward electrical connection.

Specifications

• Model: AD22-22DS
• Mounting hole diameter: 22mm
• Bulb type: LED
• Current: ≤ 20mA
• Colors: Red, green, yellow, blue, white
• Brightness: ≥ 60cd/m²
• Protection grade (standard): IP40
• Operating temperature: -25°C to +55°C
• Relative humidity: ≤ 98%
• Continual working life: ≥ 30,000 hours
