ADVU-16-20-P-A, ADVU-12-20-P-A Cylinder
Technical Specifications ComparisonBoth models share the same 20 mm stroke length but differ in piston diameter and resulting force.
| Feature | ADVU-16-20-P-A (156510) | ADVU-12-20-P-A (156503) |
|---|---|---|
| Piston Diameter | 16 mm | 12 mm |
| Piston Rod Thread | M4 Female | M3 Female |
| Force (Advance) | 121 N (at 6 bar) | 68 N (at 6 bar) |
| Force (Return) | 90 N (at 6 bar) | 51 N (at 6 bar) |
| Pneumatic Port | M5 | M5 |
| Cushioning | Elastic rings at both ends | Elastic rings at both ends |
| Position Sensing | Built-in magnet for proximity sensors | Built-in magnet for proximity sensors |
Key Common Features
- Operating Pressure: 1.2 bar to 10 bar (17.4 to 145 psi).
- Temperature Range: -20°C to +80°C.
- Materials: High-alloy stainless steel piston rods and wrought aluminium alloy barrels for durability.
- Mounting: Features through-hole mounting for easy installation in tight spaces.
