ADVU-20-30-A-P-A PNEUMATIC CYLINDER

ADVU-20-30-A-P-A PNEUMATIC CYLINDER
Part Number Breakdown

• ADVU: Compact cylinder series.
• 20: 20 mm piston diameter.
• 30: 30 mm stroke length.
• A: Position sensing capability via proximity sensors.
• P: Elastic cushioning rings/plates at both ends to absorb light impacts.
• A: Metric male piston rod thread (M10x1.25). [1, 2, 3]

Technical Specifications

• Operating Mode: Double-acting (uses compressed air to both extend and retract).
• Piston Rod Thread: M10x1.25 male thread.
• Cushioning Type: Non-adjustable flexible cushioning pads.
• Temperature Range: -20°C to 80°C.
• Material: Aluminium housing for corrosion resistance and lightweight strength. [1, 2]
