AFC1524DG with 3wire colling fan

AFC1524DG with 3wire colling fan
Wiring PinoutTo run the fan, connect the wires as follows:

• Red Wire: Positive (+24V DC).
• Black Wire: Negative/Ground.
• Third Wire (Usually Yellow, White, or Blue): Tachometer/Sensor. This sends a pulse signal indicating rotor speed. Leave it disconnected if you do not need speed monitoring.

Operational Specs

• Voltage: 24V DC
• Amperage: Usually 1.5A to 2.2A, depending on the exact sub-model. Use a power supply that matches or exceeds this current draw.
