AH3-360SDC12V Analog Time Delay Relay
Technical Specifications
- Operating Voltage: 12V DC
- Timing Range: 0 to 60 seconds (usually labeled as 6S, 60S, 6M, 60M depending on the sub-model series)
- Contact Rating: 5A at 250V AC / 5A at 30V DC (Resistive Load)
- Mounting Type: DIN Rail or Surface Mont (using an 8-pin base socket, e.g., PF083A)
- Pin Configuration: 8-Pin
💡 Key Features
- Modes: Features a slide switch on the side/face to toggle between delay modes (e.g., Mode A for delayed DPDT contacts, Mode B for instantaneous + delayed contacts).
- Accuracy: Uses CMOS IC for high operation stability and reliable repeat accuracy.
- LED Indicator: Built-in pilot lamp for easy monitoring of power and output status.
