AI-708 AC 220V Controller

AI-708 AC 220V Controller
Key Features and Specifications

• Controller Type: Artificial Intelligence PID controller with auto-tuning and self-adaptation, eliminating overshoot.
• Input Types: Universal input supporting various thermocouples (K, S, R, T, E, J, B, N) and RTDs (Pt100, Cu50), along with linear voltage/current.
• Power Supply: Standard 100-240V AC (50-60Hz) or optional 24V DC.
• Accuracy: High precision with a measurement accuracy of 0.2% F.S. (Full Scale).
• Modular Design: Supports various output options, including relay, SSR (Solid State Relay) driver, and linear current/voltage.
• Communication: RS485 communication interface is available for remote monitoring and integration with host computers.
• Dimensions: Available in multiple DIN panel sizes, including 96x96mm, 48x48mm, and 48x96mm.
• Protection: High anti-interference ability and reliable hardware design using tantalum or ceramic capacitors.

Common ApplicationsThe AI-708 is widely used in industries requiring precise environmental or process control:

• Industrial furnaces and ovens
• Plastic machinery
• Heating chambers
• Pressure and flow control systems
