AIMB-767 REV.A2 Control card
Core Specifications

• Processor Support: LGA775 Intel Core 2 Quad, Core 2 Duo, and Pentium processors with up to a 1333 MHz Front Side Bus (FSB).
• Memory Architecture: Dual-channel DDR3 800/1066 MHz SDRAM across non-ECC DIMM slots, supporting a maximum capacity of up to 4 GB.
• Integrated Graphics: Intel G41 shared memory chipset delivering dual display outputs via combinations of VGA and DVI interfaces.
• Connectivity & I/O:
  • Dual Gigabit LAN ports for redundant network architectures.
  • 4 Serial (COM) ports, where COM3 explicitly features auto-flow control and configures to RS-232, RS-422, or RS-485 standards.
  • Up to 4 USB 2.0 expansions on the rear panel header.

Procurement and Support DocumentationBecause this hardware revision belongs to a legacy lifecycle window, sourcing and documentation rely heavily on specialized industrial inventory distributors:

• Manuals & Technical Literatures: The official legacy layout documentation and setup configurations are actively cataloged through the
• Datasheet Lookups: Full structural diagrams, pinout configurations, and absolute max electrical ratings can be cross-verified via the
• Replacement & Spares Sourcing: Certified refurbished or new-old-stock components are widely tracked by part number across global e-commerce portals, such as the marketplace listings on and supply networks like

Are you currently attempting to troubleshoot a malfunctioning card, sourcing a direct drop-in replacement, or trying to determine the correct driver software compatibility for a specific operating system?
