How the AL03 Limit Switches Work

• Internal Design: The AL03 uses non-adjustable, pre-set internal micro-switches.
• Automatic Cutoff: When the inner rod reaches the end position, it triggers the internal switch to stop current flow.
• Reversal: To move the actuator back, you simply reverse the polarity of the 12V DC power supply.

Specifications

• Voltage: 12V DC
• Load Capacity: Up to 1000N (depending on exact sub-model/gear ratio)
• Adjustability: Non-adjustable after factory assembly
