AMZ043W02RDG KINSEAL HMI

AMZ043W02RDG KINSEAL HMI
Key Technical SpecificationsThis HMI is designed for industrial environments with the following hardware and software features:

• Display: 4.3-inch TFT LCD with a resolution of 480 x 272 pixels.
• Touch Interface: 4-wire industrial resistive touch screen with 4H surface hardness.
• Performance: Powered by a 32-bit 600MHz ARM9 CPU.
• Memory: Equipped with 16MB SPI Nor Flash.
• Connectivity: Features a single serial port supporting RS232, RS485, or RS422 communication. It also includes one USB 2.0 Device port and supports SD card downloads.
• Power: Operates on DC 10-30V with a rated power consumption of less than 2W.
• Durability: The front panel is IP65 rated for protection against dust and water. It is designed to work in temperatures ranging from -20°C to 60°C.
• Additional Features: Includes a built-in Real-Time Clock (RTC).
