ANT2-8208485 -V1 PEPPERL+FUCHS

ANT2-8208485 -V1 PEPPERL+FUCHS
Key Specifications

• Output Type: Provides both analog current (0–20 mA) and analog voltage (0–10 V) outputs via a 3-wire DC connection.
• Measurement Range: 2 mm to 8 mm.
• Operating Voltage: 18 V to 30 V DC.
• Installation: Non-flush mountable.
• Physical Build:
  • Housing: Nickel-plated brass in a cylindrical M18 x 1 threaded shape.
  • Sensing Face: PBT (Polybutylene terephthalate).
  • Protection: IP67 rated (dust-tight and protected against immersion).
• Operating Temperature: -25 °C to +70 °C
