Airtac AR2000 Pneumatic Air Pressure Regulator

The Airtac AR2000 is a pneumatic air pressure regulator used to adjust and maintain stable pressure for compressed air tools and equipment. It is known for its compact size, simple installation, and self-locking mechanism.

Technical specifications

• Fluid: Air

• Port size: 1/4" NPT or PT
• Adjusting pressure range: 0.05 to 0.85 MPa (7 to 121 psi)
• Maximum adjustable pressure: 0.95 MPa (135 psi)
• Proof pressure: 1.5 MPa (215 psi)
• Temperature range: 5 to 60°C (41 to 140°F)
• Body material: Aluminum die-casting forming

Key features

• Self-locking mechanism: Prevents the set pressure from being unintentionally altered by external interference.
• Compact design: The delicate and compact structure is suitable for applications where space is a concern.
