as1201f-m5-06a smc fitting

as1201f-m5-06a smc fitting
Technical Specifications

• Inlet Connection: M5 x 0.8 male metric thread with a built-in gasket seal.
• Outlet Connection: 6mm One-touch push-in fitting for easy tubing connection.
• Control Type: Meter-out operation, which accurately regulates air exhausting from an actuator to ensure smooth, stable movement.
• Operating Pressure: Ranges from a minimum of 0.1 MPa (1 bar) to a maximum of 1.0 MPa (10 bar).
• Proof Pressure: 1.05 MPa.
• Operating Temperature: Suitable for environments ranging from -5°C to 60°C.
• Compatible Tubing: Accepts Nylon, Soft Nylon, and Polyurethane (PU) pipes.
• Materials: Built with a lightweight polybutylene terephthalate (PBT) resin body and standard electroless nickel-plated brass threads for enhanced corrosion resistance.

Key Features

• Push-Lock Knob: Features a larger, ergonomic push-pull dial that locks into place quickly to prevent accidental setting drift.
• 360° Swivel Body: The body rotates freely around the mounting thread, allowing flexible piping direction during setup.
• Low Insertion Force: Optimized internal seals reduce the force required to insert tubing by up to 30% while retaining full holding strength.
