AS2-115 general-purpose variable frequency drive (VFD)

AS2-115 general-purpose variable frequency drive (VFD)
Technical SpecificationsAccording to data sheets from suppliers like , the device has the following core specifications:

• Power Output: 1.5 kW / 2 Horsepower (HP)
• Input Voltage: Single-phase (1φ) 220 VAC ±10%, 50/60 Hz
• Output Voltage: Three-phase (3φ) 220 VAC
• Output Rated Current: 7 Amperes (A)
• Output Frequency Range: 0.5 Hz to 400 Hz for standard models, or up to 2000 Hz for high-frequency configurations
• Control Method: “Sine wave pulse width modulation.”
• Cooling System: Air-cooled design
• Physical Weight: Approximately 1.3 kg net weight

Core Features

• Braking Capacity: Includes regenerative discharge braking to slow down motors safely.
• Overcurrent Protection: Capable of handling up to 150% of its rated current for 1 minute.
• Flexible Dual Settings: Configurable digitally via the onboard LED keypad or analogously via a physical frequency knob.
• Adjustable Timing: Acceleration and deceleration ramp times can be set anywhere from 0.1 to 6,000 seconds.
