Autonics AS80-50DN3 Proximity Sensor

Autonics AS80-50DN3 Inductive Proximity Sensor NPN Normally Open+Normally Closed, 50mm Sensing distance, 80mm Sensing Frame size, 150×150×1mm(iron) Standard sensing target, 30Hz Response frequency, 20mA max. Current consumption, 12~48V DC 4-wire Type, -25 to 70℃ Ambient temperature, IP67(IEC standard)

Specification/Additional Details

• Sensor Type : Inductive
• Product Type : Inductive Proximity Sensor
• Model : AS80-50DN3
• Brand : Autonics
• Control output : NPN Normally Open+Normally Closed
• Sensing side size : Frame size 80mm

• Sensing range : 50mm

• Standard sensing target : 150x150x1mm(iron)

• Response frequency : 30Hz

• Sensing type : Upper sensing type

• Supply Voltage : 12~48VDC

• Wire type : 4-wire type
