ASC100-06 AIRTAC Regulator
Technical Specifications

• Port Size: 1/8" (G1/8 or PT thread)
• Valve Type: One-way throttle / flow control valve
• Working Pressure Range: 0.05 to 0.95 MPa (7 to 135 psi)
• Proof Pressure: 1.5 MPa (215 psi)
• Operating Temperature: -20 to 70°C
• Fluid: Filtered air (40 µm)
• Flow Rates: Control flow of 200 L/min; free flow of 400 L/min
• Body Material: Aluminum alloy
• Compatibility: Acts as a functional alternative to the SMC AS series
• Key Features
  • Precise Adjustment: Equipped with a sensitive adjustment screw to control air exhaust and manage actuator speed.
  • Flexible Mounting: Supports multi-position installation in pneumatic circuits.
  You can find purchase options and availability via industrial suppliers like  or direct distributors likAre you looking for a true pressure regulator (such as the Airtac SDR series) or do you need help with thread types (G vs. NPT) for your setup?
