Schneider Electric ATV310HU15N4E Speed Drive

Schneider Electric Frequency Converter ATV310HU15N4E Variable Speed Drive 1.5kW 2hp 380 to 460V,
Schneider Electric ATV310HU15N4E Vector Inverter Speed Drive

Specification/Additional Details

• Product Type : Variable Speed Drive
• Brand : Schneider Electric
• Model : ATV310HU15N4E
• Type of module : Vector Inverter
• Max motor power : 1.5kW
• Network number of phases : Three phase
• Rated supply voltage : 380...460 V - 15...10 %

• Inverter output voltage : 3 x 400V AC

• Voltage between phases (for three phase system) : 3 x 380...460V AC

• Line current : 6.5 A at 380 V (heavy duty), 5.4 A at 460 V (heavy duty)

• Continuous output current : 4.1 A heavy duty

• Speed drive output frequency : 0.5 - 400 Hz

• Nominal switching frequency : 4 kHz

• Analogue input number : 1

• Discrete input number : 4

• Analogue output number : 1

• Discrete output number : 2

• Electrical connection : Screw terminals

• IP rating : IP20
