ATV71HU22N4Z VFD DRIVE

ATV71HU22N4Z VFD DRIVE
Key Technical Specifications

• Power Rating: 2.2 kW / 3 HP
• Input Voltage: 3-Phase, 380V to 480V AC (-15% to +10%)
• Line Current: 8.2 A at 380V / 7.1 A at 480V
• Nominal Output Current: 5.8 A at 380V / 4.8 A at 460V
• Output Frequency: 0.1 to 599 Hz
• EMC Filter: Integrated
• Communications: Built-in CANopen and Modbus protocols
• Variant Note: The "Z" suffix indicates this model comes without a built-in graphic display terminal (keypad). You will need a remote terminal or a software connection to program it.
