A6 Automatic Solder Paste Printer

A6 Automatic SMT Screen Printing Machine, Automatic Solder Paste Printer Machine A6 For SMT Solder Paste Printing,
A6 a high precision automatic solder paste screen printer designed for high precision screen printing or stencil printing in SMT industry.

• Support PCB sizes from 50mm x 50mm to 510mm x 340mm and PCB thickness from 0.4mm to 6mm
• High positional accuracy, repeated positioning accuracy ±0.01mm; printing accuracy 0.025mm
• Support glue printing.
• Automatic PCB calibration
• Squeegee pressure adjustable
• Automatic printing
• Automatic stencil cleaning (dry-type and wet-type)
• Automatic squeegee pressure balancing. Accurate pressure control ensures perfect forming effect of solder paste.
• Multi-functional PCB positioning system for convenient and accurate PCB positioning.
• Programmable PCB lifting platform ensure the PCB to lift to a proper height.
• Upward and downward visual positioning.
• Built-in image processing system.

Specification/Additional Details

• Application/Usage : PCB Printing
• Product Type : Automatic Solder Paste/Glue Printer
• Model : A6
• Type : Automatic
• Max board size : 510 x 340 mm
• Frame Size : 470 x 370 to 737 x 737 mm

• Print Speed : 6-200 mm / sec

• Printing Accuracy : +-0.025 mm

• Printing head : 2 Head

• Transport Speed : 1500mm / Second (Max), programmable

• Cycle Time : <7 sec

• Air Pressure : 4.5 - 6kg / cm2

• Vision system : Yes

• Power Supply : AC220 V +- 10%, 50 / 60HZ, 3KW

• Net Weight : 1000 kg

• Machine Dimension : 1220 x 1355 x 15005 mm
