az-8104 panasonic limit switch
Key Specifications

• Manufacturer: Panasonic
• Part Number / Model: AZ8104 (AZ-8 Series)
• Actuator: Roller arm (30mm lever radius with an 18mm plastic roller)
• Contact Configuration: SPDT / NO + NC (Normally Open + Normally Closed)
• Rated Current / Voltage (AC): 5A at 250V AC (resistive load)
• Rated Current / Voltage (DC): 0.4A at 125V DC (resistive load)
• Ingress Protection: IP64 (dust-proof, oil-tight, and splash-resistant)
• Body Material: Plastic/Composite construction
• Operating Temperature: -20°C to +60°C
• Datasheet: Available via

Common Applications

• Conveyor machinery and automated assembly lines
• General engineering and industrial machinery position detection
• Safety interlocks and robotics

If you are looking for a replacement or cross-compatible alternative to the Panasonic AZ8104, let me know whether you need help finding a currently manufactured equivalent model or supplier details.
