AZM161CC-1212RK-M16-24V SCHMERSAL SAFETY SWITCH
AZM161CC-1212RK-M16-24V SCHMERSAL SAFETY SWITCH
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
AZM161CC-1212RK-M16-24V SCHMERSAL SAFETY SWITCH
Key SpecificationsAccording to Schmersal and various merchant sites, the main specifications for this safety switch are as follows:
| Attribute | Detail |
|---|---|
| Product Type | Solenoid interlock safety switch |
| Holding Force | 2000 N |
| Housing Material | Glass-fibre reinforced thermoplastic, self-extinguishing |
| IP Rating | IP67 (dust and water resistant) |
| Operating Temperature | -25 °C to +60 °C |
| Contacts | 4 Normally Closed (NC) and 2 Normally Open (NO) safety contacts |
| Coil Voltage | 24 V AC/DC |
| Connection Type | M16 cable entries (x4) with Cage Clamp terminals |
| Operation Type | Power to Unlock (guard can be opened when power is applied) |
| Dimensions | 130 mm (width) x 90 mm (height) x 30 mm (depth) |
