bakon 191-211 replaceable temperature sensor wire Type-K thermocouple)

bakon 191-211  replaceable temperature sensor wire Type-K thermocouple)
Key Technical Specifications

• Sensor Configuration: Type-K (Chromel-Alumel) Thermocouple wire featuring a specific tri-junction weld point.
• Temperature Testing Range: 0 to 600°C.
• Primary Utility: Quick temperature calibration to protect sensitive components against overheating.
• Design Feature: Equipped with a corrosion-resistant alloy coating that extends operational lifespan when used with harsh lead-free solders.

Overview of Functionality

• Consumable Component: Because soldering tip metal and flux cause chemical erosion, these sensor wires wear down naturally and are packaged as easily replaceable units (often sold in packs of 10).
• How It Works: The wire spans across three anchored pins on the terminal deck of the BK191 tester. Technicians apply freshly tinned soldering iron tips directly onto the center tri-junction weld point at a 45-degree angle to read stable thermal outputs within seconds.
