Baumer Undk 30i6103/s14 Ultrasonic Sensor

Key Technical Specifications

• Part Number / Article ID: 10129046
• Scanning Range (Sd): 100 mm to 1000 mm
• Output Signal: Current output ranging from 4 mA to 20 mA (or inverted 20 mA to 4 mA)
• Supply Voltage Range (+Vs): 15 VDC to 30 VDC
• Sonic Frequency: 240 kHz
• Connection Type: Standard M12 connector (4-pole)
• Response / Release Time: Less than 80 ms
• Resolution: Less than 0.3 mm
• Repeat Accuracy: Less than 0.5 mm
• Operating Temperature: -10 °C to +60 °C
• Protection Class: IP 67 rated (highly resistant to dust and water ingress)

• Integrated Teach-in Button: Features a built-in button for simple, fast calibration of close and far limits without needing advanced programming.
• Visual Status Indicators: Equipped with yellow and red LEDs to provide direct alignment aid and target tracking feedback.
• Rugged Housing: Built in a durable block-style polyester housing to withstand challenging plant environments
